The heart of the electric snowmobile is designed to survive in the Arctic
The emission-free eSled’s battery module and BMS / PDU have been designed and proven to operate in harsh Arctic conditions. Proprietary module interconnection system maximizes pack level energy density.
Thermal management
The heart of the electric snowmobile is designed to survive in the Arctic. Quality state-of-the-art components keeps the battery at optimum temperature even in the toughest conditions and lets the rider squeeze every last spark out of the batteries.
Specifications
Battery | Range | Dry weight
Type
Modular Lithium-Ion NMC
Maximum voltage
120 VDC
Connector
CCS Combo 2
Charging Power (Type2)
3.3kW or 6.6kW
Charging Power (DC)
12 kW max.
Charging time (Type2)
2 h for 10%-80%
3,5 h for 0-100% (21 kWh)
Battery heating
Internal heating with resistors, located at the bottom of the module
When charging: from the grid power
When driving: powered by the
battery’s own energy
Cooling
External liquid cooling system
Battery capacity
Range*
Total weight of sled
14 kWh
65 km
235 kg
21 kWh
100 km
275 kg
* Projected overall range achievable, assuming an average speed of 25 km/h at -25 °C. Actual range may vary based on various factors and driving conditions.
